Simulation Report: dc_sim.svg
Table of Contents
1. Top-Level Schematic
2. Output Expressions
| Name | Expression | Unit | Min | Value | Max | Description |
|---|---|---|---|---|---|---|
| scalar_at_0_and_plots | showplot(sdc('V1#branch'), label="sdc('V1#branch')")
plot(sdc('V2#branch'), label="sdc('V2#branch')")
value(sdc('sweep'), sdc('N_1'), at=0) |
V | 200m | |||
| just_scalar | showvalue(sdc('sweep'), sdc('N_1'), at=0.5) |
V | 200m | 5 |
3. Waveform Plots
plotA
plot(sdc('N_2'), label="sdc('N_2')")
plotB
plot(sdc('N_2'), label="sdc('N_2')")
plot(sdc('N_1'), label="sdc('N_1')")
plotC
plot(sdc('V1#branch'), label="sdc('V1#branch')")
plot(sdc('V2#branch'), label="sdc('V2#branch')")
scalar_at_0_and_plots
plot(sdc('V1#branch'), label="sdc('V1#branch')")
plot(sdc('V2#branch'), label="sdc('V2#branch')")
value(sdc('sweep'), sdc('N_1'), at=0)
4. Simulation Logs
Click to view simulation log
*****
***** Welcome to the Xyce(TM) Parallel Electronic Simulator
*****
***** This is version Xyce Release 7.10-opensource
***** Date: Wed Mar 04 09:58:32 CET 2026
***** Executing netlist /Users/rennekef/Documents/SchematicEntry/backup/tests/simulation/dc_sim.net
***** Reading and parsing netlist...
DEBUG checkIfModelValid: device_type=M, modelType=NMOS, modelLevel=1, isModelLevelValid=1, isModelTypeValid=1, numNodes=4
***** Setting up topology...
***** Device Count Summary ...
M level 1 (MOSFET level 1) 1
V level 1 (Independent Voltage Source) 2
----------------------------------------
Total Devices 3
***** Setting up matrix structure...
***** Number of Unknowns = 4
***** Initializing...
***** Solution Summary *****
Number Successful Steps Taken: 13
Number Failed Steps Attempted: 0
Number Jacobians Evaluated: 26
Number Linear Solves: 26
Number Failed Linear Solves: 0
Number Residual Evaluations: 40
Number Nonlinear Convergence Failures: 0
Total Residual Load Time: 0.000754118 seconds
Total Jacobian Load Time: 0.000827074 seconds
Total Linear Solution Time: 0.00266838 seconds
***** Total Simulation Solvers Run Time: 0.016988 seconds
***** Total Elapsed Run Time: 0.0932062 seconds
*****
***** End of Xyce(TM) Simulation
*****
Timing summary of 1 processor
Stats Count CPU Time Wall Time
---------------------------------------- ----- --------------------- ---------------------
Xyce 1 0.035 (100.0%) 0.250 (100.0%)
Analysis 1 0.002 ( 6.58%) 0.017 ( 6.72%)
DC Sweep 1 0.002 ( 6.53%) 0.017 ( 6.70%)
Solve 13 0.002 ( 5.36%) 0.015 ( 5.84%)
Residual 40 0.000 ( 0.92%) 0.001 ( 0.32%)
Jacobian 26 0.000 ( 0.26%) 0.001 ( 0.34%)
Linear Solve 26 0.000 ( 1.16%) 0.003 ( 1.09%)
Successful Step 13 0.000 ( 0.53%) 0.001 ( 0.55%)
Netlist Import 1 0.002 ( 6.97%) 0.039 (15.76%)
Parse Context 1 0.000 ( 0.97%) 0.003 ( 1.20%)
Distribute Devices 1 0.001 ( 2.12%) 0.002 ( 0.97%)
Verify Devices 1 0.000 ( 0.03%) 0.000 (<0.01%)
Instantiate 1 0.000 ( 0.51%) 0.001 ( 0.38%)
Late Initialization 1 0.002 ( 4.44%) 0.014 ( 5.50%)
Global Indices 1 0.000 ( 0.20%) 0.000 ( 0.11%)
Setup Matrix Structure 1 0.000 ( 0.88%) 0.005 ( 1.97%)
