OpenS Suite Documentation

Welcome to OpenS, a professional-grade, open-source simulation suite designed for both integrated semiconductor and discrete electronic design. OpenS bridges the gap between open-source flexibility and the robust feature sets typically reserved for commercial EDA tools.

![OpenS Application Screenshot](assets/images/app_screenshot.png)

By providing an intuitive interface coupled with high-performance automation, OpenS empowers engineers to go beyond basic simulation into comprehensive design verification and analysis.

Key Features

  • Integrated Library & Output Management: Streamlined administration of components and complex output expressions.
  • Xyce Backend: Native support for high-performance, parallel circuit simulation.
  • Advanced Waveform Visualization: High-fidelity viewer for detailed signal analysis.
  • Programmatic Design Control: Automated design space exploration (DSE) and dynamic stimuli generation.
  • Extensible Architecture: Built for modern workflows that require more than just a schematic editor.
  • Automated Reporting: Generate professional HTML reports with one click. View Example Report.
